IN-14 Shield for Arduino Nixie Tubes Clock on a Beech Wood Stand [SMF, RGB, USB, Tunes] (Tubes, Sockets, Columns, Arduino, Power Supply) (Temp. Sensor, GPS Receiver, IR Remote)

Units Sold: 21



Shield Nixie Clock on Beech Wooden Stand with Columns
Designed for 6 IN-14 xUSSR Nixie Tubes with Sockets
IN-14 Tubes are the most popular mass-produced Nixie Tubes
Nixie Clocks are one of the most beautiful and popular Vintage Clocks
Clock features Startup Tune, RGB backlight, USB port for updates
External Temperature sensor with 3.5 mm jack included with the Clock
Accessories include Temp. sensor, GPS Receiver and IR Remote
Nixie Clock is designed for Arduino UNO and MEGA 2560 Control Boards
It allows you to write your own unique programs for the Arduino platform
All the latest source codes are always available on our GitHub channel
PCB, Design, Schematics, Case and Software made by GRA & AFCH





$149.95$329.95

Clear

IN-14 Shield for Arduino Nixie Tubes Clock with Sockets and Columns on a Beech Wood Stand



Shield Nixie Clock on Beech Wooden Stand with Columns
Designed for 6 IN-14 xUSSR Nixie Tubes with Sockets
IN-14 Tubes are the most popular mass-produced Nixie Tubes
Nixie Clocks are one of the most beautiful and popular Vintage Clocks
Clock features Startup Tune, RGB backlight, USB port for updates
External Temperature sensor with 3.5 mm jack included with the Clock
Accessories include Temp. sensor, GPS Receiver and IR Remote
Nixie Clock is designed for Arduino UNO and MEGA 2560 Control Boards
It allows you to write your own unique programs for the Arduino platform
All the latest source codes are always available on our GitHub channel
PCB, Design, Schematics, Case and Software made by GRA & AFCH







Listing includes:



  • Shield Nixie Clock with Dots [Shield Tubes Board with Arduino Control Board] on Beech Wood Stand
  • IN-14 Nixie Tubes [6 Tubes Set] (optional, choose in selector)
  • Sockets for Tubes [thin pins] [for 6 Tubes] (optional, choose in selector)
  • Columns for Dots [50mm] [2 pcs] (optional, choose in selector)
  • Arduino Control Board [UNO or MEGA 2560] (optional, choose in selector)
  • Temperature sensor [DS18B20] [3.5mm jack] (optional, choose in selector)
  • GPS Receiver [GA-6] [3.5mm jack] (only with Arduino MEGA 2560) (optional, choose in selector)
  • IR Remote [IR RMX153R] (only with Arduino MEGA 2560) (optional, choose in selector)
  • Power Supply [12V/1A] [US, EU, UK, AU] [AC plug] (optional, choose in selector)
  • Operating Instruction on vintage-style paper



Dear customers!
If you have ANY questions, PLEASE ASK us.





Our Benefits



  • Easy to build beautiful clock – we offer housing
  • A special socket (Options) for each pin IN-14 – Easy to change tubes
  • Easy to customize firmware under Your own needs, thanks to an open platform – Arduino
  • Fast uploading via USB
  • The latest version of the firmware always available on GitHub
  • No need to download drivers – we are use only Genuine USB to serial converters.
    Drivers for them pre-installed in all popular OS: Windows, MacOS, Linux
  • Human friendly menu
  • Very high qualty of Printed Circuit Boards
  • Japan alluminium capacitors
  • Power-On Self-Test
  • Technical support



Software Features



  • Time format: [HH:MM:SS]
  • Hour format: [12/24] (changable)
  • Date format: [DD:MM:YY]
  • Fully static display mode with maximum possible brightness of the Tubes
  • Automatic information update on the Tubes
  • Unique RGB LED backlight with 16,7 million colors
  • Selection of color for backlight LED or cycle through all spectrum
  • Switching the backlight LED on/off in the matter of seconds
  • Changeable RTTTL (Nokia format) sound melodies (included: Mission Impossible, We Wish You…)
  • Updatable Firmware via USB using Arduino IDE software
  • Slot Machine effect (antipoisoning – Tubes lifetime saving function)
  • Separate control for Upper and Lower Dots
  • Power-On Self-Test (POST) using Tubes, LED backlight, Sound showing firmware version at the end
  • Detailed Tubes test that checks each segment on every Tube
  • Temperature display in Celsius or Fahrenheit (optional, if Temp. sensor present)



Hardware Features



  • Integrated adjustable High Voltage Power supply: 150–220 V
  • 3 PWM channels for RGB LEDs, 8 bit per channel: 24bit, 16,7 million colors
  • Test Points for diagnostic, adjusting and control of Low and High voltage circuits
  • Internal buzzer
  • Real Time Clock (RTC) (DS3231SN) with Backup battery
  • Onboard 3-buttons controls
  • IR Receiver (TSOP4836) for IR Remote (works best with Arduino Mega)
  • Temperature sensor (DS18B20) connector with 1-wire protocol
  • 8 pcs RGB SMD backlight LEDs
  • SPI up to 4Mhz
  • PCB wirings for 2 Columns with 2 neon lamps each (Dots)
  • Reverse polarity protection
  • Power consumption, projected: 11-14 VDC, 750 mA, operational: 12 VDC, no less than 1A
  • Power supply connector dimensions: 5.5 x 2.1 mm (center pin is positive “+”)
  • Nixie Tubes Clock dimensions (without tubes): (312x 110x 90) mm / (12.28 x 4.33 x 3.54) inch



IN-14 Arduino Shield Nixie Tubes Clock on a Beech Wooden Stand by GRA & AFCH





IN-14 Arduino Shield Nixie Tubes Clock on a Wooden Stand by GRA & AFCH





Operating Instruction
